Body : DI / CF8 / CF8M
Body Fabricated
Flange:IS 2062/ASTM A 105 / SS 304 / SS316
Reducer:WPB / SS 304 / SS316
Lining:PTFE/PFA/FEP/PVDF / HDPE/PP
Lining thickness: 3mm Minimum
Flange connection:ANSI B16.5, #150/Customer requirement
➤ We are manufacturing wide range of the Reducer
Testing Data :
Hydraulic Test : -20 kg/cm²
Spark test : 15 KVDC
