Body : DI/ASTM A216 GR WCB/CF8/CF8M
Ball : SOLID PTFE
Lining : PFA/FEP/PVDF/HDPE/PP
Lining thickness : 3mm Minimum
Flange connection : ANSI B16.5, #150/Customer requirement
➤ We are manufacturing wide range of the 2pc design valves.
Dimensional Data:
|
SIZE (NB) |
F/F (mm) |
|
15 |
108 |
|
20 |
117 |
|
25 |
127 |
|
40 |
165 |
|
50 |
178 |
|
65 |
203 |
|
80 |
228 |
|
100 |
406 |
Testing Data:
Hydraulic Test : Body-15 kg/cm²
: seat-11 kg/cm²
: seat-2 kg/cm² (back pressure)
